| Varenummer | LC260EXN-SDA3 |
| Mærke | LG Display |
| Størrelse | 26.0 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LC260EXN-SDA3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 26.0 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 575.769×323.712 mm |
| omrids | 609.8×357.8×15.6 mm |
| overflade | Antiglare (Haze 10%), Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193168% |
| responstid | 6 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| LC260EUN-SCA1 | LG Display | 26.0 | 1920×1080 |
| LC260EUN-SDA1 | LG Display | 26.0 | 1920×1080 |
| LC260EUN-SDP1 | LG Display | 26.0 | 1920×1080 |
| LC260EXN-SCA1 | LG Display | 26.0 | 1366×768 |
| LC260EXN-SDA1 | LG Display | 26.0 | 1366×768 |
| LC260EXN-SDA2 | LG Display | 26.0 | 1366×768 |
| LC260EXN-SDA3 | LG Display | 26.0 | 1366×768 |
| LTA260AP01 | Samsung | 26.0 | 1366×768 |
| LTA260AP02 | Samsung | 26.0 | 1366×768 |
| T260XW06 V4 | AUO | 26.0 | 1366×768 |
| LC315TU3A | PANDA | 31.5 | 1366×768 |
| LC320EUD-SEM1 | LG Display | 31.5 | 1920×1080 |
| LC420EUN-FEF1 | LG Display | 42 | 1920×1080 |
| LC420WUE-SCV1 | LG Display | 42 | 1920×1080 |
| LC470EUN-PFF1 | LG Display | 47 | 1920×1080 |
| T370FBE1-DA | Other | 37 | 1920×1080 |
| V315B5-P10 | Innolux | 31.5 | 1366×768 |
| V420HJ2-P01 | Innolux | 42 | 1920×1080 |
| V500HJ1-LE2 | Innolux | 50 | 1920×1080 |
| V500HK1-PS6 | Innolux | 50 | 1920×1080 |
