| Varenummer | LTA750FF01 |
| Mærke | Samsung |
| Størrelse | 75 |
| Ansøgning | LCTV |
| Løsning | 3840×2160 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 5000:1 |
| Farver | 1.06B |
| Baggrundsbelysning | WLED |
| Interface | V-by-One |
| panel mærke | SAMSUNG |
| panel model | LTA750FF01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 75 inch |
| løsning | 3840(RGB)×2160 , UHD |
| visningstilstand | SPVA, Normally Black, Transmissive |
| aktivt område | 1650.24×928.26 mm |
| omrids | 1675.8×953.8×53.4 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 5000:1 (Typ.) |
| vise farver | 1.06B (8-bit + Dithering), CIE193172% |
| responstid | 6 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | V-by-One 16 lane, 107 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
