| Varenummer | M260TWR1 R1 |
| Mærke | IVO |
| Størrelse | 26.0 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | IVO |
| panel model | M260TWR1 R1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 26.0 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 575.769×323.712 mm |
| omrids | 626×373 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| HT260WX2-101 | BOE | 26.0 | 1366×768 |
| LTA260AP01 | Samsung | 26.0 | 1366×768 |
| LTA260AP02 | Samsung | 26.0 | 1366×768 |
| LTA260W2-L12 | Samsung | 26.0 | 1366×768 |
| LTY260W2-L06 | Samsung | 26.0 | 1366×768 |
| M260TWR1 R1 | IVO | 26.0 | 1366×768 |
| T260XW01 V5 | AUO | 26.0 | 1280×768 |
| T260XW04 V8 | AUO | 26.0 | 1366×768 |
| V260B3-LE2 | Innolux | 26.0 | 1366×768 |
| V260H1-LE2 | Innolux | 26.0 | 1920×1080 |
| LC230EUE-SEA1 | LG Display | 23.0 | 1920×1080 |
| LC320EUN-FFM1 | LG Display | 31.5 | 1920×1080 |
| LC370WXN-SBA1 | LG Display | 37 | 1366×768 |
| LC420DUN-SEU3 | LG Display | 42 | 1920×1080 |
| LC650EQK-FGK5 | LG Display | 65 | 3840×2160 |
| LTA400HM1C-001 | Samsung | 40 | 1920×1080 |
| LTA460HJ09 | Samsung | 46 | 1920×1080 |
| LTA550HJ15 | Samsung | 55 | 1920×1080 |
| T260XW04 V6 | AUO | 26.0 | 1366×768 |
| T390HVF01.0 | AUO | 39 | 1920×1080 |
