| Varenummer | LTD141EC7B |
| Mærke | TOSHIBA |
| Størrelse | 14.1 |
| Ansøgning | NBPC |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | Toshiba Matsushita |
| panel model | LTD141EC7B |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 14.1 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | Transmissive |
| aktivt område | 285.696×214.272 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFL |
| signal interface | LVDS (1 ch, 6-bit) |
| rohs: | |
| Ansøgning | NBPC |
| A141EW01 V0 | AUO | 14.1 | 1280×800 |
| HT14X13-101 | HYDIS | 14.1 | 1024×768 |
| LP141WP1-TLC1 | LG Display | 14.1 | 1440×900 |
| LP141WX3-TLN4 | LG Display | 14.1 | 1280×800 |
| LTD141EC7B | TOSHIBA | 14.1 | 1024×768 |
| LTD141EN9B | TOSHIBA | 14.1 | 1400×1050 |
| LTN141XB-L04 | Samsung | 14.1 | 1024×768 |
| N141C1-L01 | Innolux | 14.1 | 1440×900 |
| N141C3-L02 | Innolux | 14.1 | 1440×900 |
| QD141X1LH12 Rev.A | QDI | 14.1 | 1024×768 |
| B156XW02 V0 | AUO | 15.6 | 1366×768 |
| LP133WF6-SSA1 | LG Display | 13.3 | 1920×1080 |
| LP154WX4-TLB4 | LG Display | 15.4 | 1280×800 |
| LP156WH3-TLSA | LG Display | 15.6 | 1366×768 |
| LTM15C460F | TOSHIBA | 15.0 | 1024×768 |
| LTN121W1-L02 | Samsung | 12.1 | 1280×800 |
| LTN156AT36-D01 | Samsung | 15.6 | 1366×768 |
| LTN160AT01-A05 | Samsung | 16.0 | 1366×768 |
| N140O6-L02 | Innolux | 14.0 | 1600×900 |
| N156BGE-L21 | Innolux | 15.6 | 1366×768 |
