| Varenummer | LP154WX4-TLB4 |
| Mærke | LG Display |
| Størrelse | 15.4 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG.Philips LCD |
| panel model | LP154WX4-TLB4 20 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.4 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 331.2×207 mm |
| omrids | 344×222×6.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP154W01-TLA3 | LG Display | 15.4 | 1280×800 |
| LP154W01-TLAD | LG Display | 15.4 | 1280×800 |
| LP154W01-TLE5 | LG Display | 15.4 | 1280×800 |
| LP154WE3-TLA1 | LG Display | 15.4 | 1680×1050 |
| LP154WP3-TLA2 | LG Display | 15.4 | 1440×900 |
| LP154WT1-SJA1 | LG Display | 15.4 | 2880×1800 |
| LP154WX4-TLA1 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLA1 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLA2 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLP1 | LG Display | 15.4 | 1280×800 |
| B140RW01 V0 | AUO | 14.0 | 1600×900 |
| B156HW01 V1 | AUO | 15.6 | 1920×1080 |
| B156XTT01.0 | AUO | 15.6 | 1366×768 |
| HT14X12-101 | HYDIS | 14.1 | 1024×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| LP140WH2-TLA1 | LG Display | 14.0 | 1366×768 |
| LP154W02-B1K6 | LG Display | 15.4 | 1680×1050 |
| LP173WD1-TLN4 | LG Display | 17.3 | 1600×900 |
| LTN156AT30-W01 | Samsung | 15.6 | 1366×768 |
| N173O6-L02 | Innolux | 17.3 | 1600×900 |
