| Varenummer | LTI430LA02 |
| Mærke | Samsung |
| Størrelse | 43 |
| Ansøgning | PID |
| Løsning | 1920×480 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTI430LA02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 43 inch |
| løsning | 1920(RGB)×480 |
| visningstilstand | S-PVA, Normally Black, Transmissive |
| aktivt område | 1059.84×264.96 mm |
| omrids | 1096×301 mm |
| overflade | Antiglare (Haze 44%), Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 6 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
