| Varenummer | LTI550HN16 |
| Mærke | SAMSUNG |
| Størrelse | 55 |
| Ansøgning | Video Wall |
| Løsning | 1920×1080 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 4000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| fabrikant | SAMSUNG |
| modelnavn | LTI550HN16 |
| skærmstørrelse | 55 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1920(RGB)×1080 (FHD) 40PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 1209.6 × 680.4 (H×V) |
| omrids (mm) | 1211.6 × 682.4 × 68.1 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Antiglare (Haze 25%), Hard coating (2H) |
| luminans | 500 cd/m² (Typ.) |
| kontrastforhold | 4000 : 1 (Typ.) (TM) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| respons | 8 (Typ.)(G to G) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | SVA, Normally Black, Transmissive |
| farvedybde | 16.7M 99% sRGB |
| baggrundsbelysning | WLED , 50K hours , With LED Driver |
| splejsningssøm | 2.0 mm (active to active seam) |
| anvendes til | Video Wall |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | LVDS (2 ch, 8-bit) , Connector 51 pins |
| spændingsforsyning | 12.0V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
| LTI550FN01 | Samsung | 55 | 3840×2160 |
| LTI550HJ05 | Samsung | 55 | 1920×1080 |
| LTI550HN02 | Samsung | 55 | 1920×1080 |
| LTI550HN04 | Samsung | 55 | 1920×1080 |
| LTI550HN05 | Samsung | 55 | 1920×1080 |
| LTI550HN07 | Samsung | 55 | 1920×1080 |
| LTI550HN08 | Samsung | 55 | 1920×1080 |
| LTI550HN09 | Samsung | 55 | 1920×1080 |
| LTI550HN11 | Samsung | 55 | 1920×1080 |
| LTI550HN14 | Samsung | 55 | 1920×1080 |
