| Varenummer | LTI550HN07 |
| Mærke | Samsung |
| Størrelse | 55 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 4000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTI550HN07 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 55 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | SVA, Normally Black, Transmissive |
| aktivt område | 1209.6×680.4 mm |
| omrids | 1242.2×713×33.3 mm |
| overflade | Antiglare (Haze 44%), Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| LTI550FN01 | Samsung | 55 | 3840×2160 |
| LTI550HJ05 | Samsung | 55 | 1920×1080 |
| LTI550HN01 | Samsung | 55 | 1920×1080 |
| LTI550HN02 | Samsung | 55 | 1920×1080 |
| LTI550HN04 | Samsung | 55 | 1920×1080 |
| LTI550HN05 | Samsung | 55 | 1920×1080 |
| LTI550HN07 | Samsung | 55 | 1920×1080 |
| LTI550HN09 | Samsung | 55 | 1920×1080 |
| LTI550HN11 | Samsung | 55 | 1920×1080 |
| LTI550HN14 | Samsung | 55 | 1920×1080 |
| BRS315H2 | 31.5 | 1920×1080 | |
| BRS550H2 | BERISE | 55 | 1920×1080 |
| LD420EUP-SEA1 | LG Display | 42 | 1920×1080 |
| LD420EUP-SEB1 | LG Display | 42 | 1920×1080 |
| LD470DUE-SFR1 | LG Display | 47 | 1920×1080 |
| LD550EUD-SDA1 | LG Display | 55 | 1920×1080 |
| P550HVN02.2 | AUO | 55 | 1920×1080 |
| P550HVN06.0 | AUO | 55 | 1920×1080 |
| RX415TXP01 | ROGIN | 41.5 | 1920×540 |
| S290AJ1-LE1 | Innolux | 29.0 | 1920×540 |
