| Varenummer | LTI570HD01 |
| Mærke | Samsung |
| Størrelse | 57 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTI570HD01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 57 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | PVA, Normally Black, Transmissive |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 16.7M (8-bit) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 36 pcsCCFLEmbedded (Balance board) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
