| Varenummer | BRS550H2 |
| Mærke | BERISE |
| Størrelse | 55 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 2000 |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | BERISE |
| panel model | BRS550H2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 55 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 1209.6×680.4 mm |
| omrids | 1240.9×717.2×40.8 mm |
| overflade | Antiglare (Haze 1%), Hard coating (3H) |
| lysstyrke | 2000 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193168% |
| responstid | 6 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| BRS550H2 | BERISE | 55 | 1920×1080 |
| LC550DUE-FGP2 | LG Display | 55 | 1920×1080 |
| LC550EQK-FGK3 | LG Display | 55 | 3840×2160 |
| LC550EQN-PGF1 | LG Display | 55 | 3840×2160 |
| LC550EUE-SEU1 | LG Display | 55 | 1920×1080 |
| LC550EUG-PFF1 | LG Display | 55 | 1920×1080 |
| LC550EUJ-FFK1 | LG Display | 55 | 1920×1080 |
| LSC550FJ06-W01 | Samsung | 55 | 3840×2160 |
| LTA550HJ13 | Samsung | 55 | 1920×1080 |
| V546HK3-LS5 Rev.C7 | Innolux | 55 | 1920×1080 |
| LD420EUB-SDA1 | LG Display | 42 | 1920×1080 |
| LD420WUB-SBG1 | LG Display | 42 | 1920×1080 |
| LD470EUP-SEB1 | LG Display | 47 | 1920×1080 |
| LTI400HA06 | Samsung | 40 | 1920×1080 |
| LTI430LA02 | Samsung | 43 | 1920×480 |
| LTI460AP01-101 | Samsung | 46 | 1366×768 |
| LTI700HD01-001 | Samsung | 70 | 1920×1080 |
| P645HW03 V0 | AUO | 65 | 1920×1080 |
| P650HVN02.3 | AUO | 65 | 1920×1080 |
| RX372TXP01 | ROGIN | 37.2 | 1920×360 |
