| Varenummer | LTM121SI-T01 |
| Mærke | Samsung |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SAMSUNG |
| panel model | LTM121SI-T01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 246×184.5 mm |
| omrids | 275×205.5×10.7 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 5/25 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 41 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | IA |
| B121EW09 V3 HW0A | AUO | 12.1 | 1280×800 |
| G121XN01 V0 | AUO | 12.1 | 1024×768 |
| HT12X12-100 | HYDIS | 12.1 | 1024×768 |
| LQ121S1DG42 | SHARP | 12.1 | 800×600 |
| LTD121C35S | TOSHIBA | 12.1 | 800×600 |
| LTD121KX6B | TOSHIBA | 12.1 | 1280×800 |
| LTM121SI-T01 | Samsung | 12.1 | 800×600 |
| LTN121W3-L01 | Samsung | 12.1 | 1280×800 |
| PD121XL3 | E Ink | 12.1 | 1024×768 |
| TM121SDS01 | Tianma | 12.1 | 800×600 |
| BA121S01-100 | BOE | 12.1 | 800×600 |
| EL160.80.50 LC CC | Lumineq | 3.5 | 160×80 |
| LM-CK53-22NFR | SANYO | 9.4 | 640×480 |
| LQ104V1DG61 | SHARP | 10.4 | 640×480 |
| LTM09C016K | TOSHIBA | 9.4 | 640×480 |
| NL6448BC26-25 | NLT | 8.4 | 640×480 |
| NL6448BC33-71 | NLT | 10.4 | 640×480 |
| OEL9M0073-Y-E | Other | 1.0 | 128×64 |
| RGS24128064YW004 | RiTdisplay | 2.4 | 128×64 |
| TM121SV-A01 | SANYO | 12.1 | 800×600 |
