| Varenummer | LTM181E3-P01 |
| Mærke | Samsung |
| Størrelse | 18.1 |
| Ansøgning | DMPC |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | TMDS |
| panel mærke | SAMSUNG |
| panel model | LTM181E3-P01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 18.1 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | PVA, Normally Black, Transmissive |
| aktivt område | 359.04×287.232 mm |
| omrids | 410×335 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 200:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | Single Link TMDS, 31 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| HT190WG1-602 | BOE | 19.0 | 1440×900 |
| LM170E01-A6 | LG Display | 17.0 | 1280×1024 |
| LM215WF4-TLE1 | LG Display | 21.5 | 1920×1080 |
| LM230WF3-SLK1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLH1 | LG Display | 23.0 | 1920×1080 |
| LTM315FL01 | Samsung | 31.5 | 3840×2160 |
| M190ETN01.0 | AUO | 19.0 | 1280×1024 |
| M190PP01 V0 | AUO | 19.0 | 1440×900 |
| M240HW01 VC | AUO | 24.0 | 1920×1080 |
| TMS156WX1-01TB | Tianma | 15.6 | 1366×768 |
