| Varenummer | M190PP01 V0 |
| Mærke | AUO |
| Størrelse | 19.0 |
| Ansøgning | DMPC |
| Løsning | 1440×900 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | eDP |
| panel mærke | AUO |
| panel model | M190PP01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 19.0 inch |
| løsning | 1440(RGB)×900 , WXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 408.24×255.15 mm |
| omrids | 428×278×18.9 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | 3.4/1.6 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| A190EN02 V0 | AUO | 19.0 | 1280×1024 |
| G190ETN01.4 | AUO | 19.0 | 1280×1024 |
| G190SF01 V0 | AUO | 19.0 | 1680×342 |
| LM190E02-A4 | LG Display | 19.0 | 1280×1024 |
| LTN190W1-L01 | Samsung | 19.0 | 1680×1050 |
| M190PP01 V0 | AUO | 19.0 | 1440×900 |
| M190PW01 V0 | AUO | 19.0 | 1440×900 |
| M190PW01 V6 | AUO | 19.0 | 1440×900 |
| M190PW01 V8 | AUO | 19.0 | 1440×900 |
| SVA190WX01TB | SVA-NEC | 19.0 | 1440×900 |
| CLAA185WA04 | CPT | 18.5 | 1366×768 |
| HM215WU1-500 | BOE | 21.5 | 1920×1080 |
| LM185TT1A | PANDA | 18.5 | 1366×768 |
| LQ150X1DG10 | SHARP | 15.0 | 1024×768 |
| LTM181E3-P01 | Samsung | 18.1 | 1280×1024 |
| LTM190BT07 | Samsung | 19.0 | 1440×900 |
| LTM201M1-L01 | Samsung | 20.1 | 1680×1050 |
| LTM230HT10 | Samsung | 23.0 | 1920×1080 |
| MT190AW02 V.Y | Innolux | 19.0 | 1440×900 |
| TX43D21VC0CAA | JDI | 17.0 | 1280×1024 |
