| Varenummer | LTM240CT06 |
| Mærke | Samsung |
| Størrelse | 24.0 |
| Ansøgning | DMPC |
| Løsning | 1920×1200 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTM240CT06 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 24.0 inch |
| løsning | 1920(RGB)×1200 , WUXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 518.4×324 mm |
| omrids | 546.4×350×11.2 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S3PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LM240WU7-SLA3 | LG Display | 24.0 | 1920×1200 |
| LM240WU8-SLA3 | LG Display | 24.0 | 1920×1200 |
| LTM240CL01 | Samsung | 24.0 | 1920×1200 |
| LTM240CL04 | Samsung | 24.0 | 1920×1200 |
| LTM240CS02 | Samsung | 24.0 | 1920×1200 |
| LTM240CS09 | Samsung | 24.0 | 1920×1200 |
| LTM240CT01 | Samsung | 24.0 | 1920×1200 |
| LTM240CT03 | Samsung | 24.0 | 1920×1200 |
| LTM240CT04 | Samsung | 24.0 | 1920×1200 |
| LTM240CT06 | Samsung | 24.0 | 1920×1200 |
| HT190WG3-500 | BOE | 19.0 | 1440×900 |
| LM150X08-TLB1 | LG Display | 15.0 | 1024×768 |
| LM201U04-SL03 | LG Display | 20.1 | 1600×1200 |
| LM215WF3-SLA1 | LG Display | 21.5 | 1920×1080 |
| LM270WF5-SLA1 | LG Display | 27.0 | 1920×1080 |
| LTM230HU01 | Samsung | 23.0 | 1920×1080 |
| M150XN07 V9 | AUO | 15.0 | 1024×768 |
| M185B1-L07 | Innolux | 18.5 | 1366×768 |
| M238HVN01.0 | AUO | 23.8 | 1920×1080 |
| MT170EN01 V.C | Innolux | 17.0 | 1280×1024 |
