| Varenummer | LM201U04-SL03 |
| Mærke | LG Display |
| Størrelse | 20.1 |
| Ansøgning | DMPC |
| Løsning | 1600×1200 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG.Philips LCD |
| panel model | LM201U04-SL03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.1 inch |
| løsning | 1600(RGB)×1200 , UXGA |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 408×306 mm |
| omrids | 432×331.5×25.5 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 7/9 (Typ.)(Tr/Td); 12 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 20.0V (Typ.) |
| Ansøgning | DMPC |
