| Varenummer | LTN133AT09-W01 |
| Mærke | Samsung |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN133AT09-W01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 13.3 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 286.08×178.8 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | WLED |
| signal interface | LVDS (1 ch, 6-bit) |
| Ansøgning | NBPC |
| LTN133AT05-001 | Samsung | 13.3 | 1280×800 |
| LTN133AT15-G01 | Samsung | 13.3 | 1280×800 |
| LTN133AT16-L01 | Samsung | 13.3 | 1280×800 |
| LTN133AT23-803 | Samsung | 13.3 | 1366×768 |
| LTN133AT23-B01 | Samsung | 13.3 | 1366×768 |
| LTN133AT23-C01 | Samsung | 13.3 | 1366×768 |
| LTN133AT23-X01 | Samsung | 13.3 | 1366×768 |
| LTN133AT25-T01 | Samsung | 13.3 | 1366×768 |
| LTN133AT27-102 | Samsung | 13.3 | 1366×768 |
| LTN133AT27-205 | Samsung | 13.3 | 1366×768 |
| B140HAN01.1 | AUO | 14.0 | 1920×1080 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| LP154WE2-TLA7 | LG Display | 15.4 | 1680×1050 |
| LT121S1-101 | Samsung | 12.1 | 800×600 |
| LTM08C356F | TOSHIBA | 8.4 | 800×600 |
| LTN156AT20-P02 | Samsung | 15.6 | 1366×768 |
| LTN170WX-L06 | Samsung | 17.0 | 1440×900 |
| N144NGE-E41 | Innolux | 14.4 | 1792×768 |
| N156BGE-LB1 | Innolux | 15.6 | 1366×768 |
| N173FGE-L21 | Innolux | 17.3 | 1600×900 |
