| Varenummer | LTN133YL01-F01 |
| Mærke | Samsung |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 3200×1800 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | SAMSUNG |
| panel model | LTN133YL01-F01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 13.3 inch |
| løsning | 3200RG(BW)×1800 , Quad-HD+ |
| visningstilstand | PLS, Normally Black, Transmissive |
| aktivt område | 293.44×165.06 mm |
| omrids | 306.15×188.2 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 11S5PWLEDEmbedded (LED Driver) |
| signal interface | eDP (4 Lanes), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
