| Varenummer | LTD104EA5R |
| Mærke | TOSHIBA |
| Størrelse | 10.4 |
| Ansøgning | NBPC |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 170 |
| CR | 100:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | Toshiba Matsushita |
| panel model | LTD104EA5R |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 210.4×157.8 mm |
| omrids | 237.1×173.2×4.9 mm |
| overflade | |
| lysstyrke | 170 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Min.) |
| vise farver | 262K (6-bit) |
| responstid | 50/50 (Max.)(Tr/Td) |
| synsvinkel | 40/40/20/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LTD104C11S | TOSHIBA | 10.4 | 640×480 |
| LTD104C11U | TOSHIBA | 10.4 | 640×480 |
| LTD104C11Z | TOSHIBA | 10.4 | 640×480 |
| LTD104EA5F | TOSHIBA | 10.4 | 1024×768 |
| LTD104EA5R | TOSHIBA | 10.4 | 1024×768 |
| LTD104EA5S | TOSHIBA | 10.4 | 1024×768 |
| LTD104EA5W | TOSHIBA | 10.4 | 1024×768 |
| LTD104EDQP | TOSHIBA | 10.4 | 1024×768 |
| LTD104EDZS | TOSHIBA | 10.4 | 1024×768 |
| LTD106EWNN | TOSHIBA | 10.6 | 1280×768 |
| B140HAN01.3 | AUO | 14.0 | 1920×1080 |
| B140QAN01.0 | AUO | 14.0 | 2560×1440 |
| LP154W02-B1K6 | LG Display | 15.4 | 1680×1050 |
| LP154WU1-A1K3 | LG Display | 15.4 | 1920×1200 |
| LP156WH3-TPS2 | LG Display | 15.6 | 1366×768 |
| LTD104EDZS | TOSHIBA | 10.4 | 1024×768 |
| LTN140AT21-801 | Samsung | 14.0 | 1366×768 |
| LTN156AT02 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-H02 | Samsung | 15.6 | 1366×768 |
| LTN156AT32-L01 | Samsung | 15.6 | 1366×768 |
