| Varenummer | LTN141AT13-H01 |
| Mærke | Samsung |
| Størrelse | 14.1 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN141AT13-H01 6 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 303.36×189.6 mm |
| omrids | 319.5×205.5×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Min.) |
| vise farver | 262K (6-bit) |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LTN141AT05-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT05-G03 | Samsung | 14.1 | 1280×800 |
| LTN141AT08-304 | Samsung | 14.1 | 1280×800 |
| LTN141AT12-W03 | Samsung | 14.1 | 1280×800 |
| LTN141AT13-H01 | Samsung | 14.1 | 1280×800 |
| LTN141AT15-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-001 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-002 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-003 | Samsung | 14.1 | 1280×800 |
| LTN141AT16-B03 | Samsung | 14.1 | 1280×800 |
| B125XW02 V0 | AUO | 12.5 | 1366×768 |
| B133HAN02.1 | AUO | 13.3 | 1920×1080 |
| B140HAN01.2 | AUO | 14.0 | 1920×1080 |
| B156HAK01.0 | AUO | 15.6 | 1920×1080 |
| B173HW01 V5 | AUO | 17.3 | 1920×1080 |
| LP140WH4-TLD1 | LG Display | 14.0 | 1366×768 |
| LQ133T1JW02 | SHARP | 13.3 | 2560×1440 |
| LTD121EDFN | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXPD | TOSHIBA | 12.1 | 1280×800 |
| N141C1-L05 | Innolux | 14.1 | 1440×900 |
