| Varenummer | B125XW02 V0 |
| Mærke | AUO |
| Størrelse | 12.5 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | B125XW02 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 276.615×155.52 mm |
| omrids | 291.7×173.7×5.2 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 6/2 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B125XW01 V0 | AUO | 12.5 | 1366×768 |
| B125XW02 V0 | AUO | 12.5 | 1366×768 |
| LP125WF2-SPB2 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLT2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPM2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| M125NWR3 R0 | IVO | 12.5 | 1366×768 |
| N125HCE-GN1 | Innolux | 12.5 | 1920×1080 |
| B121EW09 V2 | AUO | 12.1 | 1280×800 |
| B133HAN02.1 | AUO | 13.3 | 1920×1080 |
| B140RTN02.1 | AUO | 14.0 | 1600×900 |
| B141EW01 V3 | AUO | 14.1 | 1280×800 |
| LP150E07-A3K1 | LG Display | 15.0 | 1400×1050 |
| LP154W01-TLA3 | LG Display | 15.4 | 1280×800 |
| LP156WD1-TLA2 | LG Display | 15.6 | 1600×900 |
| LP171WP4-TL03 | LG Display | 17.1 | 1440×900 |
| LTD133EWHK | TOSHIBA | 13.3 | 1280×800 |
| LTN156HL01 | Samsung | 15.6 | 1920×1080 |
