| Varenummer | LTN170X2-L02 |
| Mærke | Samsung |
| Størrelse | 17.0 |
| Ansøgning | NBPC |
| Løsning | 1440×900 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN170X2-L02 2 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1440(RGB)×900 , WXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 367.2×229.5 mm |
| omrids | 382.2×244.5×6.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare or Glare, Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/20/25 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LTN170BT06-G01 | Samsung | 17.0 | 1440×900 |
| LTN170BT08-G01 | Samsung | 17.0 | 1440×900 |
| LTN170BT09-001 | Samsung | 17.0 | 1440×900 |
| LTN170CT07-G01 | Samsung | 17.0 | 1920×1200 |
| LTN170CT08-D01 | Samsung | 17.0 | 1920×1200 |
| LTN170U1-L02 | Samsung | 17.0 | 1920×1200 |
| LTN170WA-L01 | Samsung | 17.0 | 1440×900 |
| LTN170WX-L06 | Samsung | 17.0 | 1440×900 |
| LTN170X2-L02 | Samsung | 17.0 | 1440×900 |
| LTN170X2-L03 | Samsung | 17.0 | 1440×900 |
| B140EW01 V5 | AUO | 14.0 | 1280×768 |
| B140XTN03.5 | AUO | 14.0 | 1366×768 |
| LP154WX7-TLB3 | LG Display | 15.4 | 1280×800 |
| LQ133M1JW03 | SHARP | 13.3 | 1920×1080 |
| LQ150X1LAM3 | SHARP | 15.0 | 1024×768 |
| LTN133AT23-001 | Samsung | 13.3 | 1366×768 |
| LTN154AT08-001 | Samsung | 15.4 | 1280×800 |
| LTN156KT01-003 | Samsung | 15.6 | 1600×900 |
| LTN170WX-L06 | Samsung | 17.0 | 1440×900 |
| NT156WHM-N50 | BOE | 15.6 | 1366×768 |
