| Varenummer | M236HJJ-P02 |
| Mærke | Innolux |
| Størrelse | 23.6 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | CHIMEI INNOLUX |
| panel model | M236HJJ-P02 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 23.6 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | Super MVA, Normally Black, Transmissive |
| aktivt område | 521.28×293.22 mm |
| omrids | 534.28×306.252 mm |
| overflade | Antiglare (Haze 3%), Hard coating (3H) |
| transmissivitet | 4.6% (Typ.)(with Polarizer) |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 10 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
