| Varenummer | NL256204AM15-02A |
| Mærke | NLT |
| Størrelse | 20.1 |
| Ansøgning | DMPC |
| Løsning | 2560×2048 |
| Sammensætning | LCM |
| Lysstyrke | 850 |
| CR | 600:1 |
| Farver | Grayscale |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | NEC |
| panel model | NL256204AM15-02A |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.1 inch |
| løsning | 2560(LCR)×2048 , QSXGA |
| visningstilstand | SA-SFT, Normally Black, Transmissive |
| aktivt område | 399.36×319.49 mm |
| omrids | 423.4×343.5×45.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 850 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | Grayscale (8-bit) |
| responstid | 15/15 (Typ.)(Tr/Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 12 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (4 ch, 8-bit) |
| indgangsspænding | 12.0V (Typ.) |
| rohs: | |
| Ansøgning | DMPC |
| LM201U04-A3KC | LG Display | 20.1 | 1600×1200 |
| LM201U04-SL03 | LG Display | 20.1 | 1600×1200 |
| LM201U05-SLL1 | LG Display | 20.1 | 1600×1200 |
| LM201W01-STB1 | LG Display | 20.1 | 1680×1050 |
| LM201WE2-SLA1 | LG Display | 20.1 | 1680×1050 |
| LM201WE4-TLB2 | LG Display | 20.1 | 1680×1050 |
| LQ201U1LW32 | SHARP | 20.1 | 1600×1200 |
| M201EW02 V6 | AUO | 20.1 | 1680×1050 |
| NL256204AM15-02A | NLT | 20.1 | 2560×2048 |
| V201B1-L01 | Innolux | 20.1 | 1366×768 |
| HSD190MEN3-A01 | HannStar | 19.0 | 1280×1024 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| LM190WX1-TLC1 | LG Display | 19.0 | 1440×900 |
| LM215WF3-SLA1 | LG Display | 21.5 | 1920×1080 |
| LM300WQ5-SLA1 | LG Display | 30.0 | 2560×1600 |
| LTM190M2-L31 | Samsung | 19.0 | 1440×900 |
| LTM240CT01 | Samsung | 24.0 | 1920×1200 |
| M215HW01 VB | AUO | 21.5 | 1920×1080 |
| M270HW01 V0 | AUO | 27.0 | 1920×1080 |
| M270MWN1 R0 | IVO | 27.0 | 1920×1080 |
