| Varenummer | MC57T04L |
| Mærke | Other |
| Størrelse | 5.7 |
| Ansøgning | IA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 120 |
| CR | 30:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | Arima |
| panel model | MC57T04L |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 5.7 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 115.2×86.4 mm |
| omrids | 154.6×114.8×10.5 mm |
| overflade | Antiglare |
| lysstyrke | 120 cd/m² (Typ.) |
| kontrastforhold | 30:1 (Min.) |
| vise farver | Color |
| responstid | 250/200 (Typ.)(Tr/Td) |
| synsvinkel | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel Data (8-bit), 15 pins |
| indgangsspænding | 3.3V (Typ.) |
| rohs: | |
| Ansøgning | IA |
