| Varenummer | MT220WW01 V.5 |
| Mærke | Innolux |
| Størrelse | 22.0 |
| Ansøgning | DMPC |
| Løsning | 1680×1050 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | INNOLUX |
| panel model | MT220WW01 V.5 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 22.0 inch |
| løsning | 1680(RGB)×1050 , WSXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 473.76×296.1 mm |
| omrids | 493.7×320.1×16.7 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193192% |
| responstid | 1.5/3.5 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| CLAA215FA04 V4 | CPT | 21.5 | 1920×1080 |
| HM236WU3-100 | BOE | 23.6 | 1920×1080 |
| HR215WU1-120 | BOE | 21.5 | 1920×1080 |
| HSD170MGW1-B00 | HannStar | 17.0 | 1440×900 |
| HT185WX1-100 | BOE | 18.5 | 1366×768 |
| LM150X08-TLB1 | LG Display | 15.0 | 1024×768 |
| LM240WU3-TLD1 | LG Display | 24.0 | 1920×1200 |
| LTM213U6-L01 | Samsung | 21.3 | 1600×1200 |
| LTM230HT09 | Samsung | 23.0 | 1920×1080 |
| M185XW01 VH | AUO | 18.5 | 1366×768 |
