| Varenummer | MT5461D01-3 |
| Mærke | CSOT |
| Størrelse | 55 |
| Ansøgning | LCTV |
| Løsning | 3840×2160 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 4000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | V-by-One |
| panel mærke | CSOT |
| panel model | MT5461D01-3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 55 inch |
| løsning | 3840(RGB)×2160 , UHD |
| visningstilstand | HVA, Normally Black, Transmissive |
| aktivt område | 1209.6×680.4 mm |
| omrids | 1225.8×696.6 mm |
| overflade | Antiglare (Haze 2%), Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 1.07B (8-bit + Hi-FRC), CIE193172% |
| responstid | 6.5 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | V-by-One 8 lane, 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| LC550EGE-FHM1 | LG Display | 55 | 3840×2160 |
| LC550EGY-SHM2 | LG Display | 55 | 3840×2160 |
| LC550EUF-FFP2 | LG Display | 55 | 1920×1080 |
| LC550EUJ-SFK2 | LG Display | 55 | 1920×1080 |
| LD550DUN-THA3 | LG Display | 55 | 1920×1080 |
| LTA550HJ07 | Samsung | 55 | 1920×1080 |
| MT5461D01-1 | CSOT | 55 | 3840×2160 |
| MT5461D01-3 | CSOT | 55 | 3840×2160 |
| T546HW01 V0 | AUO | 55 | 1920×1080 |
| V546HK3-LS5 Rev.C7 | Innolux | 55 | 1920×1080 |
| LC320WUD-SCA1 | LG Display | 31.5 | 1920×1080 |
| LC370WXN-SBA1 | LG Display | 37 | 1366×768 |
| LC500DUE-SFR1 | LG Display | 50 | 1920×1080 |
| LK600D3LA3K | SHARP | 60 | 1920×1080 |
| LTA320HJ03 | Samsung | 31.5 | 1920×1080 |
| LTA550HQ14 | Samsung | 55 | 1920×1080 |
| T400XW01 V7 | AUO | 40 | 1366×768 |
| T420HVN06.1 | AUO | 42 | 1920×1080 |
| V236BJ1-P01 | Innolux | 23.6 | 1366×768 |
| V260B1-L02 | Innolux | 26.0 | 1366×768 |
