| Varenummer | MV185WHB-N20 |
| Mærke | BOE |
| Størrelse | 18.5 |
| Ansøgning | Desktop Monitor |
| Løsning | 1366×768 |
| Sammensætning | a-Si TFT-LCD, CELL |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No |
| Interface | LVDS |
| mærke | BOE |
| model | MV185WHB-N20 |
| diagonal størrelse | 18.5 inch |
| type | a-Si TFT-LCD, CELL |
| pixel format | 1366(RGB)×768 [WXGA] 84PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 409.8(H)×230.4(V) mm |
| omrids dim. | 422.2(H)×244.1(V) ×1.32(D) mm |
| bezel område | - |
| behandling | Antiglare (Haze 25%), Hard coating (3H) |
| luminans | 0 cd/m² |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 14 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| driftstilstand | HADS, Normally Black, Transmissive |
| pladetykkelse | 0.50+0.50 mm |
| transmission | 6.0% (Typ.)(with Polarizer) |
| støtte farve | 16.7M 72% NTSC |
| lyskilde | No B/L |
| vægt | 327g (Typ.) |
| designet til | Desktop Monitor |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| d-ic detalje | COF Built-in 2 source chips |
| interface type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Strømforsyning | 5.0V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| G185HAN01.0 | AUO | 18.5 | 1920×1080 |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| LTA185AT01 | Samsung | 18.5 | 1366×768 |
| LTM185AT02 | Samsung | 18.5 | 1366×768 |
| M185B1-L02 | Innolux | 18.5 | 1366×768 |
| M185XW01 VF | AUO | 18.5 | 1366×768 |
| MT185GW01 V.4 | Innolux | 18.5 | 1366×768 |
