| Varenummer | N156BGA-EB3 |
| Mærke | Innolux |
| Størrelse | 15.6 |
| Ansøgning | Laptop |
| Løsning | 1366×768 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| mærke | Innolux |
| model | N156BGA-EB3 (CMN15FD) |
| diagonal størrelse | 15.6 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1366(RGB)×768 [WXGA] 100PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 344.232(H)×193.536(V) mm |
| omrids dim. | 350.73(H)×216.56(V) ×3.2(D) mm |
| bezel område | - |
| behandling | Glare (Haze 0%), Hard coating (3H) |
| luminans | 220 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) (TM) |
| visningsretning | 6 o'clock |
| responstid | 3/7 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/45 (Typ.)(CR≥10) |
| driftstilstand | TN, Normally White, Transmissive |
| støtte farve | 262K 45% NTSC |
| lyskilde | WLED , 15K hours , With LED Driver |
| form stil | Slim (PCBA Flat, T≤3.2mm) |
| designet til | Laptop |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
