| Varenummer | N156B3-L02 |
| Mærke | Innolux |
| Størrelse | 15.6 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | N156B3-L02 11 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 344.232×193.536 mm |
| omrids | 359.3×209.5×6.2 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 3/5 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| N156B3-L01 | Innolux | 15.6 | 1366×768 |
| N156B3-L02 | Innolux | 15.6 | 1366×768 |
| N156B6-L04 | Innolux | 15.6 | 1366×768 |
| N156BGE-E21 | Innolux | 15.6 | 1366×768 |
| N156BGE-E42 | Innolux | 15.6 | 1366×768 |
| N156BGE-EB1 | Innolux | 15.6 | 1366×768 |
| N156BGE-L41 | Innolux | 15.6 | 1366×768 |
| N156BGE-L51 | Innolux | 15.6 | 1366×768 |
| N156BGE-L62 | Innolux | 15.6 | 1366×768 |
| N156BGE-LB1 | Innolux | 15.6 | 1366×768 |
| LP116WF1-SPA1 | LG Display | 11.6 | 1920×1080 |
| LP150E07-A2 | LG Display | 15.0 | 1400×1050 |
| LP154W02-B1K6 | LG Display | 15.4 | 1680×1050 |
| LP171WU8-SLB1 | LG Display | 17.1 | 1920×1200 |
| LT121SU-121 | Samsung | 12.1 | 800×600 |
| LTM10C321N | TOSHIBA | 10.4 | 1024×768 |
| LTN154AT08-001 | Samsung | 15.4 | 1280×800 |
| LTN156AT34-D01 | Samsung | 15.6 | 1366×768 |
| NT140WHM-N31 | BOE | 14.0 | 1366×768 |
| NT156WHM-N10 | BOE | 15.6 | 1366×768 |
