| Varenummer | N156O6-L01 |
| Mærke | Innolux |
| Størrelse | 15.6 |
| Ansøgning | NBPC |
| Løsning | 1600×900 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | N156O6-L01 10 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 1600(RGB)×900 , HD+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 344.16×193.59 mm |
| omrids | 359.3×209.5×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193156% |
| responstid | 3/5 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S6PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B156XTN02.0 | AUO | 15.6 | 1366×768 |
| B156XW01 V1 | AUO | 15.6 | 1366×768 |
| B156XW04 V5 | AUO | 15.6 | 1366×768 |
| CLAA156WA15A | CPT | 15.6 | 1366×768 |
| LQ156D1JX01 | SHARP | 15.6 | 3840×2160 |
| LTN156AT02-D04 | Samsung | 15.6 | 1366×768 |
| N156B6-L0B | Innolux | 15.6 | 1366×768 |
| N156O6-L01 | Innolux | 15.6 | 1600×900 |
| N156O6-L02 | Innolux | 15.6 | 1600×900 |
| N156O6-L04 | Innolux | 15.6 | 1600×900 |
| B133HAT02.5 | AUO | 13.3 | 1920×1080 |
| B133XTN01.2 | AUO | 13.3 | 1366×768 |
| B141PW04 V0 HW2A | AUO | 14.1 | 1440×900 |
| HB140WX1-301 | BOE | 14.0 | 1366×768 |
| LM12S389 | SHARP | 12.1 | 800×600 |
| LP140WH2-TLN1 | LG Display | 14.0 | 1366×768 |
| LTN121AT10-301 | Samsung | 12.1 | 1280×800 |
| LTN121W1-L03 | Samsung | 12.1 | 1280×800 |
| LTN156AT35-W02 | Samsung | 15.6 | 1366×768 |
| N121IA-L02 | Innolux | 12.1 | 1280×800 |
