| Varenummer | N173FGE-L23 |
| Mærke | Innolux |
| Størrelse | 17.3 |
| Ansøgning | NBPC |
| Løsning | 1600×900 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 650:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CHIMEI INNOLUX |
| panel model | N173FGE-L23 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.3 inch |
| løsning | 1600(RGB)×900 , HD+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 382.08×214.92 mm |
| omrids | 398.1×232.8×5.8 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 650:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 3/7 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S5PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| BT140GW01 V.0 | Innolux | 14.0 | 1366×768 |
| CLAA133UA01 | CPT | 13.3 | 1600×900 |
| LP140WH4-TLA1 | LG Display | 14.0 | 1366×768 |
| LP150E07-A3 | LG Display | 15.0 | 1400×1050 |
| LTD121KX4K | TOSHIBA | 12.1 | 1280×800 |
| LTD141EN9B | TOSHIBA | 14.1 | 1400×1050 |
| LTN133AT23-001 | Samsung | 13.3 | 1366×768 |
| LTN184KT01-F01 | Samsung | 18.4 | 1680×945 |
| N133B6-L01 | Innolux | 13.3 | 1366×768 |
| N141X6-L01 | Innolux | 14.1 | 1024×768 |
