| Varenummer | N173HGE-L11 |
| Mærke | Innolux |
| Størrelse | 17.3 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 650:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CHIMEI INNOLUX |
| panel model | N173HGE-L11 3 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.3 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 381.888×214.812 mm |
| omrids | 398.1×232.8×6 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 650:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193172% |
| responstid | 2/6 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B173HW01 V5 | AUO | 17.3 | 1920×1080 |
| G173HW01 V0 | AUO | 17.3 | 1920×1080 |
| HSD173PUW1-A01 | HannStar | 17.3 | 1920×1080 |
| LP173WD1-TLN1 | LG Display | 17.3 | 1600×900 |
| LP173WF1-TLB3 | LG Display | 17.3 | 1920×1080 |
| LP173WF4-SPD1 | LG Display | 17.3 | 1920×1080 |
| N173HCE-E31 | Innolux | 17.3 | 1920×1080 |
| N173HGE-E11 | Innolux | 17.3 | 1920×1080 |
| N173HGE-L11 | Innolux | 17.3 | 1920×1080 |
| B140XTN03.3 HW0A | AUO | 14.0 | 1366×768 |
| LP141WP2-TLB1 | LG Display | 14.1 | 1440×900 |
| LP154WE3-TLA1 | LG Display | 15.4 | 1680×1050 |
| LP171WU6-TLA2 | LG Display | 17.1 | 1920×1200 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LTD111EWAS | TOSHIBA | 11.1 | 1366×768 |
| LTN140AT18-201 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-802 | Samsung | 14.0 | 1366×768 |
| M140NWR1 R0 | IVO | 14.0 | 1366×768 |
| N141C1-L02 | Innolux | 14.1 | 1440×900 |
