| Varenummer | NL192108AC21-04 |
| Mærke | NLT |
| Størrelse | 18.5 |
| Ansøgning | Industrial |
| Løsning | 1920×1080 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| fabrikant | NLT |
| skærmstørrelse | 18.5 inch |
| pixel antal | 1920(RGB)×1080 (FHD) 119PPI |
| aktivt område (mm) | 408.96 × 230.04 (H×V) |
| rammeareal (mm) | 413.4 × 234.0 (H×V) |
| luminans | 400 cd/m² (Typ.) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10) |
| god udsigt kl | Symmetry |
| farvedybde | 16.7M 72% NTSC |
| masse | 1.55/1.70Kgs (Typ./Max.) |
| opdateringshastighed | 60Hz |
| signaltype | LVDS (2 ch, 8-bit) , 30 pins Connector |
| spændingsforsyning | 5.0V (Typ.) |
| max. vurderinger | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| modelnavn | NL192108AC21-04 |
| skærmtype | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| omrids (mm) | 430.4 × 254.6 × 14 (H×V×D) |
| behandling | Antiglare, Hard coating (3H) |
| kontrastforhold | 1000 : 1 (Typ.) (TM) |
| respons | 12/13 (Typ.)(Tr/Td) ms |
| arbejdstilstand | UA-SFT, Normally Black, Transmissive |
| baggrundsbelysning | WLED , 50K hours , With LED Driver |
| anvendes til | Industrial |
| berøringsskærm | Without |
| HT185WX1-300 | BOE | 18.5 | 1366×768 |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LM185TT4A | PANDA | 18.5 | 1366×768 |
| LTM185AT01 | Samsung | 18.5 | 1366×768 |
| M185BGE-L2U | Innolux | 18.5 | 1366×768 |
| M185XTN01.2 | AUO | 18.5 | 1366×768 |
| M185XW01 V8 | AUO | 18.5 | 1366×768 |
| MT185GW01 V.0 | Innolux | 18.5 | 1366×768 |
| MT185WHM-N20 | BOE | 18.5 | 1366×768 |
| NL192108AC10-01D | NLT | 9.0 | 1920×1080 |
