| Varenummer | NL192108AC10-01D |
| Mærke | NLT |
| Størrelse | 9.0 |
| Ansøgning | IA |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 700:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | NLT |
| panel model | NL192108AC10-01D |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | UA-SFT, Normally Black, Transmissive |
| aktivt område | 198.72×111.78 mm |
| omrids | 214.6×130×9.6 mm |
| overflade | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| responstid | 13/12 (Typ.)(Tr/Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 6/8-bit), 50 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
