| Varenummer | OC550DQH-5000 |
| Mærke | No Brand |
| Størrelse | 55 |
| Ansøgning | Digital Signage Outd |
| Løsning | 3840×2160 |
| Sammensætning | a-Si TFT-LCD , LCM |
| Lysstyrke | |
| CR | 1200:1 |
| Farver | 16.7M/1.07B |
| Baggrundsbelysning | WLED |
| Interface | V-by-One |
| mærke | No Brand |
| diagonal størrelse | 55 inch |
| pixel format | 3840(RGB)×2160 [UHD] 80PPI |
| aktivt område | 1209.6(H)×680.4(V) mm |
| bezel område | - |
| luminans | 5000 cd/m² (Typ.) |
| visningsretning | Symmetry |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10) |
| støtte farve | 16.7M/1.07B 72% NTSC |
| vægt | 15.5Kgs (Typ.) |
| billedhastighed | 60Hz |
| interface type | V-by-One 8 lane , 51 pins Connector |
| Strømforsyning | 12.0V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | OC550DQH-5000 |
| type | a-Si TFT-LCD , LCM |
| konfiguration | RGB Vertical Stripe |
| omrids dim. | 1246.6(H)×715.5(V) ×68(D) mm |
| behandling | Antiglare (Haze 1%), Hard coating (3H) |
| kontrastforhold | 1200:1 (Typ.) (TM) |
| responstid | 8 (Typ.)(G to G) |
| driftstilstand | IPS, Normally Black, Transmissive |
| lyskilde | WLED , 30K hours , W/O Driver |
| designet til | Digital Signage Outdoor High Brightness |
| berøringspanel | Without |
