| Varenummer | OEL9M5001-R-E |
| Mærke | Other |
| Størrelse | 2.7 |
| Ansøgning | |
| Løsning | 128×64 |
| Sammensætning | OLED |
| Lysstyrke | |
| CR | 10000:1 |
| Farver | Grayscale(R) |
| Baggrundsbelysning | self |
| Interface | CPU/SPI |
| panel mærke | TRULY |
| panel model | OEL9M5001-R-E |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 2.7 inch |
| løsning | 128×64 |
| aktivt område | 61.41×30.69 mm |
| omrids | 73×40.24×2.15 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 10000 : 1 (Min.) |
| vise farver | Grayscale(R) (4-bit) |
| synsvinkel | 80/80/80/80 (Min.)(L/R/U/D) |
| frekvens | 100Hz |
| driver ic | TAB Built-in SSD1325T6R1 |
| signal interface | 8-bit 6800/8080 parallel, SPI, 30 pins |
| indgangsspænding | 3.0/13.0V (Typ.)(VDD/VCC) |
| OEL9M5001-B-E | Other | 2.7 | 128×64 |
| OEL9M5001-G-E | Other | 2.7 | 128×64 |
| OEL9M5001-R-E | Other | 2.7 | 128×64 |
| OEL9M5001-W-E | Other | 2.7 | 128×64 |
| OEL9M5001-Y-E | Other | 2.7 | 128×64 |
| OEL9M5003-B-E | Other | 2.7 | 128×64 |
| OEL9M5003-G-E | Other | 2.7 | 128×64 |
| OEL9M5003-R-E | Other | 2.7 | 128×64 |
| OEL9M5003-W-E | Other | 2.7 | 128×64 |
| OEL9M5003-Y-E | Other | 2.7 | 128×64 |
| AT056TN52 V.5 | Innolux | 5.6 | 640×480 |
| C-51849NFJ-SLW-ADN | Kyocera | 5.6 | 40×4 |
| DMC-40202NY-LY-AZE-BDN | Kyocera | 5.8 | 40×2 |
| HSD101PFW1-B00 | HannStar | 10.1 | 1024×576 |
| HT15X31-100 | HYDIS | 15.0 | 1024×768 |
| LMS250GF01 | Samsung | 2.5 | |
| LTA070B240F | TOSHIBA | 7.0 | 480×234 |
| OEL9M0083-G-E | Other | 0.96 | 128×64 |
| SC2002A | Other | 2.9 | 20×2 |
| SC2004C | Other | 2.9 | 20×4 |
