| Varenummer | C-51849NFJ-SLW-ADN |
| Mærke | Kyocera |
| Størrelse | 5.6 |
| Ansøgning | |
| Løsning | 40×4 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 5:1 |
| Farver | Monochrome |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | Kyocera |
| panel model | C-51849NFJ-SLW-ADN |
| paneltype | FSTN-LCD , LCM |
| panelstørrelse | 5.6 inch |
| visningsformat | 40 characters × 4 lines |
| visningstilstand | STN, Black/White (Positive), Transflective |
| vise skrifttyper | 5×8 dots |
| tegnstørrelse | 2.78×4.89 mm |
| karakter tonehøjde | 3.53×6.09 mm |
| aktivt område | 140.45×23.16 mm |
| bezel område | 147.0×29.5 mm |
| omrids | 190×54×14.6 mm |
| lysstyrke | |
| kontrastforhold | 5:1 (Typ.)(Transmissive) |
| vise farver | Monochrome (1-bit) |
| responstid | 80/130 (Typ.)(Tr/Td) |
| lampe type | 3 pcsWLEDWithout Driver |
| signal interface | 8-bit parallel, 18 pins |
| indgangsspænding | 5.0V (Typ.) |
