| Varenummer | PA050DS7 |
| Mærke | E Ink |
| Størrelse | 5.0 |
| Ansøgning | CNS |
| Løsning | 320×234 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 350:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | PVI |
| panel model | PA050DS7 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 320(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 102.72×74.53 mm |
| omrids | 127.4×92.8×13.4 mm |
| overflade | Antiglare |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | Full color |
| responstid | 15/30 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Analog RGB + Composite Video (NTSC/PAL), 20 pins |
| indgangsspænding | 5.0/5.0/17.0/-15.0V (Typ.)(VCC/VDD/VGH/VGL) |
| Ansøgning | CNS |
