| Varenummer | PA050XS7 |
| Mærke | E Ink |
| Størrelse | 5.0 |
| Ansøgning | CNS |
| Løsning | 320×234 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 350:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | PVI |
| panel model | PA050XS7 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 320(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 102.72×74.53 mm |
| omrids | 126.4×92.3×13.2 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | Full color |
| responstid | 15/30 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 30 pins |
| indgangsspænding | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| Ansøgning | CNS |
| PA050DS2T1 | E Ink | 5.0 | 320×234 |
| PA050DS4 | E Ink | 5.0 | 320×234 |
| PA050DS7 | E Ink | 5.0 | 320×234 |
| PA050DS7N1 | E Ink | 5.0 | 320×234 |
| PA050DT2 | E Ink | 5.0 | 320×234 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| PA050XSG | E Ink | 5.0 | 320×234 |
| PA050XSH | E Ink | 5.0 | 320×234 |
| PA050XU4 | E Ink | 5.0 | 320×234 |
| AC070MD01 | Mitsubishi | 7.0 | 800×480 |
| AT102TN03 V.8 | Innolux | 10.2 | 800×480 |
| C043GW01 V0 | AUO | 4.3 | 400×234 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| FG0700K5DSSWBG01 | Data Image | 7.0 | 800×480 |
| LA061WQ1-TD05 | LG Display | 6.1 | 480×272 |
| LQ070Y5DG11 | SHARP | 7.0 | 800×480 |
| LQ088H9DZ03 | SHARP | 8.8 | 640×240 |
| TX31D16VM2BAA | KOE | 12.2 | 1024×310 |
