| Varenummer | PM070WU1 |
| Mærke | E Ink |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | PVI |
| panel model | PM070WU1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 166.3×105.3×10.3 mm |
| overflade | Antiglare |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 5/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 3S11PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.)(VCC) |
| rohs: | |
| Ansøgning | CNS |
| AT102TN03 V.3 | Innolux | 10.2 | 800×480 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| L5F30705T10 | Epson | 5.0 | 400×240 |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LA092WV1-SD01 | LG Display | 9.2 | 800×480 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LB080WV4-A1 | LG Display | 8.0 | 800×480 |
| LQ6BW506 | SHARP | 5.8 | 400×234 |
| LQ7BW566AH | SHARP | 7.0 | 480×234 |
| LTA070B052F | TOSHIBA | 7.0 | 800×480 |
