| Varenummer | RGS08096032WR001 |
| Mærke | RiTdisplay |
| Størrelse | 0.80 |
| Ansøgning | IA |
| Løsning | 96×32 |
| Sammensætning | OLED |
| Lysstyrke | 120 |
| CR | 2000:1 |
| Farver | Mono(White) |
| Baggrundsbelysning | self |
| Interface | SPI/I²C |
| panel mærke | RiTdisplay |
| panel model | RGS08096032WR001 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 0.80 inch |
| løsning | 96×32 |
| aktivt område | 19.18×6.38 mm |
| omrids | 28.5×11.5×1.51 mm |
| overflade | Antiglare |
| lysstyrke | 120 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Min.) |
| vise farver | Mono(White) (1-bit) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 105Hz |
| driver ic | COG Built-in SSD1307 |
| signal interface | 4-wire SPI, I²C, 12 pins |
| indgangsspænding | 12/2.8V (Typ.)(VCC/VDD) |
| Ansøgning | IA |
