| Varenummer | SG2701B01-3 |
| Mærke | CSOT |
| Størrelse | 27.0 |
| Ansøgning | Desktop Monitor Gami |
| Løsning | 1920×1080 |
| Sammensætning | a-Si TFT-LCD, CELL |
| Lysstyrke | |
| CR | 4000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No |
| Interface | LVDS |
| mærke | CSOT |
| model | SG2701B01-3 |
| diagonal størrelse | 27.0 inch |
| type | a-Si TFT-LCD, CELL |
| pixel format | 1920(RGB)×1080 [FHD] 81PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 597.888(H)×336.312(V) mm |
| omrids dim. | 608.888(H)×348.337(V) ×1.3(D) mm |
| bezel område | - |
| behandling | Antiglare (Haze 25%) |
| luminans | 0 cd/m² |
| kontrastforhold | 4000:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 12 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| driftstilstand | HVA, Normally Black, Transmissive |
| pladetykkelse | 0.40+0.50 mm |
| transmission | 4.6% (Typ.)(with Polarizer) |
| støtte farve | 16.7M 99% sRGB |
| lyskilde | No B/L |
| vægt | - |
| designet til | Desktop Monitor Gaming |
| billedhastighed | 165Hz |
| berøringspanel | Without |
| d-ic detalje | COF Built-in 6 source chips |
| interface type | LVDS (4 ch, 8-bit) , 61 pins Connector |
| Strømforsyning | 12.0V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
