| Varenummer | LTM270HL02 |
| Mærke | Samsung |
| Størrelse | 27.0 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTM270HL02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 27.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | PLS, Normally Black, Transmissive |
| aktivt område | 597.888×336.312 mm |
| omrids | 630×368.2×12.2 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 15 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 13S3PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LM270WF5-SLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF6-SSZ1 | LG Display | 27.0 | 1920×1080 |
| LTM270DL02 | Samsung | 27.0 | 2560×1440 |
| LTM270DL04 | Samsung | 27.0 | 2560×1440 |
| LTM270DL06 | Samsung | 27.0 | 2560×1440 |
| LTM270HL02 | Samsung | 27.0 | 1920×1080 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| LTM270TT01 | Samsung | 27.0 | 2048×1152 |
| P270HVN01.0 | AUO | 27.0 | 1920×1080 |
| CLAA260WU09 | CPT | 25.5 | 1920×1200 |
| FLC38XGC6V-06P | Fujitsu | 15.0 | 1024×768 |
| LM181E06-A4M1 | LG Display | 18.1 | 1280×1024 |
| LM190E08-TLJ8 | LG Display | 19.0 | 1280×1024 |
| LTM220M3-L02 | Samsung | 22.0 | 1680×1050 |
| LTM300M1-P02 | Samsung | 30.0 | 2560×1600 |
| M220Z3-LA3 | Innolux | 22.0 | 1680×1050 |
| M236HGK-L30 | Innolux | 23.6 | 1920×1080 |
| NL160120BC27-14 | NLT | 21.3 | 1600×1200 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
