| Varenummer | T240XW01 V0 |
| Mærke | AUO |
| Størrelse | 24.0 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 320 |
| CR | 2500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | T240XW01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 24.0 inch |
| løsning | 1366×768(RGB) , WXGA |
| visningstilstand | VA, Normally Black, Transmissive |
| aktivt område | 531.72×298.94 mm |
| omrids | 580×347.5 mm |
| overflade | Antiglare (Haze 11%), Hard coating (3H) |
| lysstyrke | 320 cd/m² (Typ.) |
| kontrastforhold | 2500:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 6.5 (Typ.)(Tr+Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| G240UAN01.0 | AUO | 24.0 | 1920×1200 |
| LM240WU4-SLB1 | LG Display | 24.0 | 1920×1200 |
| LM240WU7-SLB1 | LG Display | 24.0 | 1920×1200 |
| LM240WU8-SLD2 | LG Display | 24.0 | 1920×1200 |
| LM240WUA-SSA1 | LG Display | 24.0 | 1920×1200 |
| M240HW01 V8 | AUO | 24.0 | 1920×1080 |
| M240HW02 V1 | AUO | 24.0 | 1920×1080 |
| M240UW01 V3 | AUO | 24.0 | 1920×1200 |
| T240XW01 V0 | AUO | 24.0 | 1366×768 |
| T240XW01 V1 | AUO | 24.0 | 1366×768 |
| LC320EUD-SDA2 | LG Display | 31.5 | 1920×1080 |
| LC320WXN-SAC1 | LG Display | 31.5 | 1366×768 |
| LC470WUL-SBT1 | LG Display | 47 | 1920×1080 |
| LC550EUE-SEF1 | LG Display | 55 | 1920×1080 |
| T315XW03 V3 | AUO | 31.5 | 1366×768 |
| T430QVN01.0 CELL | AUO | 43 | 3840×2160 |
| T460HVF01.1 | AUO | 46 | 1920×1080 |
| V315B5-LE2 | Innolux | 31.5 | 1366×768 |
| V315H4-LE3 | Innolux | 31.5 | 1920×1080 |
| V650HP1-PS6 Rev.C1 | Innolux | 65 | 1920×1080 |
