| Varenummer | T315XW02 VK |
| Mærke | AUO |
| Størrelse | 31.5 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 540 |
| CR | 2500:1 |
| Farver | 1.07B |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | T315XW02 VK |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 31.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | AMVA, Normally Black, Transmissive |
| aktivt område | 697.685×392.256 mm |
| omrids | 741×435 mm |
| overflade | Antiglare (Haze 11%), Hard coating (3H) |
| lysstyrke | 540 cd/m² (Typ.) |
| kontrastforhold | 2500:1 (Typ.) |
| vise farver | 1.07B (10-bit), CIE193188% |
| responstid | 6.5 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 16 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 10-bit), 41 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
