| Varenummer | T400XW01 V1 |
| Mærke | AUO |
| Størrelse | 40 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 430 |
| CR | 1500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | T400XW01 V1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 40 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | AMVA, Normally Black, Transmissive |
| aktivt område | 885.168×497.664 mm |
| omrids | 952×551 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 430 cd/m² (Typ.) |
| kontrastforhold | 1500:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 15/8 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Min.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | CCFLEmbedded (Balance board) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | LCTV |
| LTA400HA08 | Samsung | 40 | 1920×1080 |
| LTA400HL04 | Samsung | 40 | 1920×1080 |
| LTA400HL10 | Samsung | 40 | 1920×1080 |
| LTA400WT-L09 | Samsung | 40 | 1366×768 |
| LTI400HA03 | Samsung | 40 | 1920×1080 |
| T400HW04 V1 | AUO | 40 | 1920×1080 |
| T400XW01 V1 | AUO | 40 | 1366×768 |
| T400XW01 V2 | AUO | 40 | 1366×768 |
| T400XW01 V6 | AUO | 40 | 1366×768 |
| T400XW01 V7 | AUO | 40 | 1366×768 |
| LC420EUF-SDF1 | LG Display | 42 | 1920×1080 |
| LC420EUH-SCA1 | LG Display | 42 | 1920×1080 |
| LC420EUJ-SFK2 | LG Display | 42 | 1920×1080 |
| LC470EUF-FFP1 | LG Display | 47 | 1920×1080 |
| LTZ320AB02 | Samsung | 31.5 | 1366×768 |
| T260XW02 V0 | AUO | 26.0 | 1366×768 |
| T420HVN02.1 | AUO | 42 | 1920×1080 |
| T650QVR03.0 | AUO | 65 | 3840×2160 |
| V400H1-L10 | Innolux | 40 | 1920×1080 |
| V420H2-LN1 | Innolux | 42 | 1920×1080 |
