| Varenummer | TCG121XGLPAPNN-AN20-S |
| Mærke | Kyocera |
| Størrelse | 12.1 |
| Ansøgning | Industrial |
| Løsning | 1024×768 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 750:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | Kyocera |
| model | TCG121XGLPAPNN-AN20-S |
| diagonal størrelse | 12.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×768 [XGA] 105PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 245.76(H)×184.32(V) mm |
| omrids dim. | 260.5(H)×203.4(V) ×10.8(D) mm |
| bezel område | 249.0(H)×187.5(V) mm |
| behandling | Antiglare |
| luminans | 500 cd/m² (Typ.) |
| kontrastforhold | 750:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 18/12 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| driftstilstand | AWV, Normally Black, Transmissive |
| støtte farve | 262K/16.2M 50% NTSC |
| lyskilde | WLED , 50K hours , With LED Driver |
| vægt | 670g |
| designet til | Industrial |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
| AA121SL09 | Mitsubishi | 12.1 | 800×600 |
| AA121SL12 | Mitsubishi | 12.1 | 800×600 |
| AA121TD02 | Mitsubishi | 12.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LM12S472 | SHARP | 12.1 | 800×600 |
| LMG9980ZWCC-01 | KOE | 12.1 | 800×600 |
| LP121WX3-TLA1 | LG Display | 12.1 | 1280×800 |
| LTD121EWEK | TOSHIBA | 12.1 | 1280×800 |
| N121I7-L01 | Innolux | 12.1 | 1280×800 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
