| Varenummer | LMG9980ZWCC-01 |
| Mærke | KOE |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 70 |
| CR | 30:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | HITACHI |
| panel model | LMG9980ZWCC-01 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | STN, Normally Black |
| aktivt område | 246×184.5 mm |
| omrids | 275×202.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 70 cd/m² (Typ.) |
| kontrastforhold | 30 : 1 (Typ.) |
| vise farver | Color |
| responstid | 170/130 (Typ.)(Tr/Td) |
| synsvinkel | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| frekvens | 120Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel Data (8-bit), 41 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VDD) |
| Ansøgning | IA |
