| Varenummer | TD036THEA1 |
| Mærke | TPO |
| Størrelse | 3.6 |
| Ansøgning | |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | Toppoly |
| panel model | TD036THEA1 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 3.6 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 72.96×54.72 mm |
| omrids | 80.2×66.3 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 13/22 (Typ.)(Tr/Td) |
| synsvinkel | 50/20/40/40 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 3S2PWLED |
| signal interface | Serial RGB (8-bit) + SPI, CCIR601, 39 pins |
| rohs: |
