| Varenummer | TR-LM7WR3PS |
| Mærke | Panasonic |
| Størrelse | 7.0 |
| Ansøgning | DPF |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | |
| Farver | |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | Panasonic |
| panel model | TR-LM7WR3PS |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 154.08×86.58 mm |
| omrids | 167.5×102.4 mm |
| overflade | Antiglare |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | |
| responstid | |
| synsvinkel | 60/60/30/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFL |
| signal interface | Analog RGB, 14 pins |
| indgangsspænding | 12/12V (Typ.)(VI/VBL) |
| Ansøgning | DPF |
